SMB003-0100-9 Sandwich Mounts Unc Thread Type 1
Item # SMB003-0100-9 — SMB003-0100-9 Sandwich Mounts Unc Thread Type 1 / Manufacturer: LORD Corporation
Flex-Bolt® Sandwich Mounts are Manufactured by LORD Corporation.
Need a custom part similar to SMB003-0100-9 Sandwich Mounts Unc Thread Type 1? Request a custom quote or give us a call at 888-842-5668.
A (in)
0.38
B (in)
0.38
C (in)
0.5
Compression Spring Rate Kc (Imperial)
285
Compression Spring Rate Kc (Metric)
50
Compression Static Load (lbs)
17
Compression Static Load (Metric)
76
D (in)
0.38
Durometer
59
Elastomer
Oil Resistant Elastomer - Neoprene
Grade per SAE J429
1
Manufacturer
Parker LORD
Shear Spring Rate Ks (lbs/in)
50
Shear Spring Rate Ks (Metric)
9
Shear Static Load (lbs)
3
Shear Static Load (Metric)
13
Thread Size
8-32 UNC
Thread Type
Standard UNC
Types
1
